D45S DTH Drilling Tools Hammer Cop44 DHD340 for Stone Quarry Drilling

1pcs
MOQ
Negotiate
giá bán
D45S DTH Drilling Tools Hammer Cop44 DHD340 for Stone Quarry Drilling
Đặc trưng Bộ sưu tập Mô tả sản phẩm Yêu cầu báo giá
Đặc trưng
Thông số kỹ thuật
Model: Down The Hole Hammer
Mining Object: Mining, Ore Machinery, Stone Quarry
Usage: Use Together With DTH Button Bits
Model No: DHD360, QL60, SD80, COP64, COP84
Series No: SD, ROS, COP, BR, DHD, Mission
Material: High Carbon Steel
Applications: DTH Drilling. Coal Mining, Quarry
Drill Diameter: 65-305mm
Machine: Hydraulic Crawler Drill Rig
Drilling: Down The Hole Drilling, DTH Drilling
Tools: Top Hammer Drilling Tools
HS Code: 82071990
Điểm nổi bật:

dth drilling tools

,

down hole tools

Thông tin cơ bản
Nguồn gốc: GERMANY,CHINA
Hàng hiệu: ROSCHEN
Chứng nhận: ISO,CE
Số mô hình: ROS34
Thanh toán
chi tiết đóng gói: Wooden Box
Khả năng cung cấp: 5000pcs
Mô tả sản phẩm

D45S DTH Hammer (Cop44, DHD340)


D45S DTH Hammer Cop44, DHD340 Down The Hole Hammer for Stone Quarry Drilling




DOWN THE HOLE DRILLING HAMMERS



DTH hammer is used for drilling holes through a wide range of rock types, the variety of which continues to extend well beyond the original conception of early blast hole drilling.

Down-the-Hole refers to where the hammer action occurs when compared to drifter hammers, which hammer on top of the drill string. The DTH hammer piston always makes direct contact with the drill bit and there is generally no loss of transmitted energy as the hammer drills deeper, as is the case with drifter (top hammer) rigs.



Roschen offers a wide range of DTH hammers suitable for a variety of drilling operations. Our Down the Hole hammers provide the most versatile and cost effective rock drilling method.



Basic Info
Model NO Cop44, DHD340
Mining Object Mining
Origin Germany,China
Type Drilling Machine
Trademark ROSCHE
HS Code 84123100
Mining Object Minging, Ore Machinery, Stone Quarry
Usage Use Together with DTH Button Bits
Aplication DTH Drilling. Coal Mining, Quarry
Drill Diameter 65-305mm
Transport Package Plywood






Description:

It is a kind of high air pressure DTH Hammer without footvalve, our newest design. It is also one of the most advanced DTH Hammers in the world.




It has the following advantages:

1. Out of the trouble of foot valve fracture and expansion and contraction.

2. Lower energy consumption and higher impact frequency. The drilling speed is 15%-30% higher than      the one with foot valve.

3. Simple structure, reliable parts, long life, easy and cheap maintenance.

4. Lower air and oil consumption. The oil consumption is about 10% lower than the one with foot valve.





Length (exclude bit) Weight (exclude bit) External Diameter Bit Shank Hole Range Connection Thread
986 mm 37.20 kg Φ92 mm Cop44 DHD340 Φ105mm ~ Φ120mm API 2 3/8'' Reg
Working Pressure Impact rate at 0.5 MPa Recommended Rotary Speed Air Consumption
1.0 MPa 1.8 MPa 2.4 MPa
1.0~2.5 MPa 30 Hz 25~40 rpm 5 m³/min 8 m³/min 13 m³/min






DTH hammers Specifications
Hammer Size Bit Shank ROSCHEN Code Connection Thread Suitable bit Working pressure Air consumption
2" BR2 ROS 11 ROS 22 RD50 box ¢70-¢90mm 0.7-1.75Mpa 0.7Mpa 4.5m3/min
1.0Mpa 4m3/min
1.4Mpa 5m3/min
3" DHD3.5 ROS 32 API 2 3/8" Reg ¢90-¢110mm 1.0-1.5Mpa 1.0Mpa 4.5m3/min
COP32/COP34
M30 1.5Mpa 9m3/min
4" DHD340 ROS 34 API 2 3/8" Reg ¢110-¢135mm 1.0-2.5Mpa 1.0Mpa 6m3/min
COP44
QL40
SD4 1.8Mpa 10m3/min
M40 2.4Mpa 15m3/min
5" DHD350 ROS 52 ROS 54 API 2 3/8"Reg/API 3 1/2" Reg ¢135-¢155mm 1.0-2.5Mpa 1.0Mpa 9m3/min
COP54
QL50
SD5 1.8Mpa 15m3/min
M50 2.4Mpa 23m3/min
6" DHD360 ROS 62 ROS 64 API 3 1/2" Reg ¢155-¢190mm 1.0-2.5Mpa 1.0Mpa 10m3/min
COP64
QL60
SD6 1.8Mpa 20m3/min
M60 2.4Mpa 28.5m3/min
8" DHD380 ROS 82 ROS 84 API 4 1/2" Reg ¢195-¢254mm 1.0-2.5Mpa 1.0Mpa 15m3/min
COP84
QL80 1.8Mpa 26m3/min
SD8 2.4Mpa 34m3/min
10" SD10 ROS 100 API 6 5/8" Reg ¢254-¢311mm 1.0-2.5Mpa 1.0Mpa 22m3/min
Numa100 1.8Mpa 40m3/min
ROS 100 2.4Mpa 55m3/min
12" DHD1120 ROS 120 API 6 5/8" Reg ¢305-¢445mm 1.0-2.5Mpa 1.0Mpa 30m3/min
SD12 1.8Mpa 56m3/min
Numa120 2.4Mpa 78m3/min
Notes: Metzke, Remet thread is available!
