Quarry Rock Drilling Button Bits Grinding Pin , Diamond button bits grinder 6mm - 25mm

1 set
MOQ
Quarry Rock Drilling Button Bits Grinding Pin , Diamond button bits grinder 6mm - 25mm
Đặc trưng Bộ sưu tập Mô tả sản phẩm Yêu cầu báo giá
Đặc trưng
Thông số kỹ thuật
Điểm nổi bật:

diamond core drilling bits

,

concrete core drill bit

Thông tin cơ bản
Nguồn gốc: Germany
Hàng hiệu: ROSCHEN
Chứng nhận: ISO9001
Số mô hình: For the size of button bits 6-25 mm
Thanh toán
chi tiết đóng gói: wooden box
Mô tả sản phẩm



Quarry Rock Drilling Button Bits Grinding Pin , Diamond button bits grinder 6mm - 25mm


Button bit grinder



Quick Details
Place of Origin:  Germany Brand Name:  ROSCHEN
Model Number:  RS100 Shape:  Cup-Shaped
Abrasive:  Diamond Bonding Agent:  Metal
Size:  Various Size Application:  Quarrying, Mining, Engineering
Size dia.:  7-20mm Usage:  Sharpening the button bits
Bits Dia,:  6-25mm Color:  Blue, Yellow, Green
Condition:  New Shank:  Normally 8mm or 9mm
Bits Shape:  Hemispherical, Ballistic, Semi Ballistic, Paraboloid or Conical pins Equipment:  Button bits grinder
Type:  Grinding Pin




Packaging & Delivery:



Packaging Details:    Wooden cases/cartons or according to your specific requirements FOR Hot Sales Quarry Rock Drilling Button Bits Diamond Grinding Pin
Delivery Detail:    In stock or within 25days




Specifications



1 Button bit diamond grinding pin
2 Grind the button and steel both
3 For button size 6mm-25mm
4 Four models are vailable


Hot Sales Quarry Rock Drilling Button Bits Diamond Grinding Pin

Our factory specializing in producing diamond Button Bits grinding cups/ grinding pin. It's a perfect tool for grinding your broken/worn button bits, to prolong it's lifespan.


Standard AIR / WATER ways on grinding pin


Quarry Rock Drilling Button Bits Grinding Pin , Diamond button bits grinder 6mm - 25mm 0

1). Single-water way is suitable for all insert shapes and all types of grinding machines.

2). The 3-water ways are standard on all grinding pin larger than 14mm. Gives a better redressing result, longer life of the grinding pin.





Models & Details



We have different models:

8mm shank model,

9mm shank model,

internal hex drive model,

55-drive model.

Our grinding pin can be used for grinding 7mm-25mm button size. Other sizes available on request.



Except 55-drive model, the others model all can be used for grinding both the bit button and body steel in one operation.

The combination grinding pin benefits from a specially developed grinding material capable of grinding both carbide and steel at a regular and consistent rate.





For bit's button shape For bit's button size (mm)
spherical buttons ballistic buttons 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25
bit's body steel removal 7-8 9-10 11-12 13-14 15-16 17-18 19-20



 Available with a choice of Hemispherical, Ballistic Semi Ballistic, Paraboloid or Conical cups.



Quarry Rock Drilling Button Bits Grinding Pin , Diamond button bits grinder 6mm - 25mm 1
Quarry Rock Drilling Button Bits Grinding Pin , Diamond button bits grinder 6mm - 25mm 2
